How To Install Battery – Samsung Galaxy Mega
Learn how to install battery on your Samsung Galaxy Mega. Prior to use it is necessary to install both the battery and SIM into their corresponding internal compartments. The microSD card slot is also located in this same internal area.
Insert the battery into the opening on the back of the phone, making sure the connectors align(1).
Gently press down to secure the battery(2).
Installing the Back Cover
Place the battery cover onto the back of the phone (1) and press down (2).
Removing the Back Cover
Remove the back cover by inserting a fingernail into the slot on the top of your phone (1) then lift the cover up (2).
Charging a Battery
Your device is powered by a rechargeable Li-ion battery. The Travel Charger that is used to charge the battery, is included with your device. Use only Samsung-approved batteries and chargers.
You must fully charge the battery before using your phone for the first time. A discharged battery recharges fully in approximately 4 hours.
Long backlight settings, searching for service, vibrate mode, web browser use, and other variables may reduce the batterys talk and standby times.
Although you can use the phone while the battery is charging, doing so will require additional charging time.
Using the Travel Charger
Note: Verify that the handset battery is installed prior to connection. If the battery is not properly installed and the wall charger is connected, the handset may power off and on continuously, preventing proper operation.
Plug the flat end of the Travel Charger into the Power/ Accessory Interface connector and the other end into a standard AC wall outlet. 2.
When charging is finished, remove the flat end from the interface connector jack on the phone.
Low Battery Indicator
When the battery is weak and only a few minutes of talk time remain, the battery icon blinks and the device sounds a warning tone at regular intervals. In this condition, your phone conserves its remaining battery power, not by turning off the backlight, but by entering the dimming mode. For a quick check of your battery level, glance at the battery charge indicator located in the upper-right corner of your devices display. Solid color indicates a full charge.When the battery level becomes too low, the phone automatically turns off.
